Documentation of TRNBpy Tool

0. Configuration

Configuration involves selecting the parameters. All paths and variables used are listed in the config.y file. The main parameters that the user is prompted to enter are:

• The relative path to the scenario file.

• The level of precision for buildings Precision_BLD in the three methods studied in this research (Detailed, Tailored, Prototype).

• The level of precision for the operational assumptions Precision_EXP, which determines whether variability and noise should be added.

• The level of precision for the district heating network Precision_THN, which defines the topology and load groupings within the district heating network (and thus specifies which subfolder generated by PipingTool to use).

1. Model Generation

Model generation (green path) is broken down into several steps. Their roles are detailed below.

1.1 Preparing Spacetypes

The first step is to prepare the schedules. For each spacetype, the annual schedules are stored in a CSV file. It is easier for humans to write daily schedules than schedules broken down into one-hour time steps. That is why TRNBpy includes a function to generate annual schedules from daily schedules provided as input in a CSV file (for weekdays, Saturdays, and Sundays, for each desired profile). We use these annual schedules as inputs for the B18 model because this allows for a more flexible definition (to add vacations and holidays, for example). The associated functions can be found in _SiteDataBuilder.py.

1.2 Generating JSON Files for Buildings

In this section, we proceed in several steps. These steps can be found in _jsonbuilder.py.

1. First, we generate a data structure in JSON format, listing each zone in a building along with its main properties (ID, name, area, volume, exterior surface area, floor, etc.). These characteristics are extracted from the building’s B18 file. In the future, when TRNSYS natively supports JSON files for its buildings, this step can be omitted.

2. Next, we assign a spacetype to each thermal zone. There are two methods for doing this. The first method is “manual,” where each type of thermal zone corresponds to a single spacetype. The second method is “conditional,” where each type of thermal zone corresponds to a set of spacetypes and their average representation. For example: {“Restaurant”: 0.2; ‘Retail’: 0.6; “Theater”: 0.2}. The sum must equal 1, and the representation corresponds to the desired percentage of the spacetype’s area relative to the building’s total area. The spacetype assigned to each thermal zone is then stored in the zone’s properties within the building’s JSON file. This “conditional” method allows for the distribution of different commercial zones and, in certain scenarios, introduces variability into residential spaces.

3. Third, for each zone, if the assigned spacetype includes certain gains, ventilation, or infiltration whose values depend on the zone’s geometric characteristics, then the values of these objects are recalculated. For example, the value of the lighting gain for a thermal zone depends on the zone’s floor area. Thus, once the spacetype has been assigned and stored in a zone’s characteristics, we can update the lighting gain since we know the zone’s floor area.

1.3 Noise Generation

Noise generation function are in the NoiseBuilder.py file. Finally, if the scenario is configured to have variable occupancy assumptions, functions to add noise are called in order to vary the values of certain gains and schedules. The buildings’ JSON files are thus read, edited, and saved. Noise is introduced for internal heat gains, DHW, and ventilation using a random selection algorithm within a specified range, while ensuring that the sum (or rather the average) of the values for each object remains constant. Introducing noise into the schedules involves reading the annual schedule file, identifying transition periods (for example, when the heating setpoint changes from 18°C to 24°C at 8:00 a.m.), and then shifting these transition periods within a fixed interval (for example, the heating setpoint changes from 18°C to 24°C randomly between 6 a.m. and 10 a.m.). Thus, for each schedule and for each transition period, the developed algorithm randomly selects a time within the fixed interval. The values are then adjusted to shift the transition to the randomly selected time.

1.4 Conversion to the B18 Format

Based on our discussions with TRNSOLAR, it appears that TRNSYS19 is moving toward a more text-based data structure using the JSON format. This is the basis for our development decision. However, for the time being, TRNSYS18 uses the text-based .B18 format for building files. This is why we need to convert the main building files so that they can be interpreted by the software as of today. To this end, the building input files (also in .B18 format, since the SketchUp3D extension is intended for TRNSYS18) are updated using writing functions to add the inputs, outputs, gains, ventilation, infiltration, schedules, etc., specific to each thermal zone of the building. These conversion functions can be found in _TranslateToB18.py.

1.5 DCK Generation

In this section, the tool’s objective is to generate a DCK file that links a .B18 building file with the CSV file containing its input schedules, the desired weather file, and the building’s output boxes in order to generate the desired output CSV files. Several functions are used for this purpose in the deckbuilder.py file.

2. Calculation of Building Loads

The calculation of building loads uses the Load builder file. It follows the same model for all three building modeling approaches. First, identify groups of thermal zones (i.e., clusters); next, calculate the loads for these clusters; and finally, determine the building loads based on the respective areas of the clusters in the desired models and buildings.

ScalingMethods

2.1 Definition of Clusters

The definition of thermal zone groupings depends entirely on the chosen modeling approach. First, note that for each building, we associate one or more models to be used for calculating loads, and that this association guides the definition of clusters.

• For the detailed approach, the geometry of the models accurately reflects that of the buildings. Thus, a single model is associated with each building; for example, the loads on the ground floor of a model correspond to the loads on the ground floor of the modeled building. The only exception is that the central floors are reduced to a single central floor in the models. For each building, the grouping by thermal zone accounts for this by defining each cluster as the set of zones on the same floor.

• For the reference-based approach, the geometry is simplified and does not directly represent the buildings. However, each building has been assigned a single model that includes at least all of the building’s uses. Here, scaling must ensure that the proportions of each use are maintained. For each building, this involves defining a cluster as the set of zones on the same floor and of the same spacetype.

• For the prototype approach, in keeping with the inspiration from the DOE database, we consider that each model corresponds to a single spacetype. Here, each building has been assigned as many models as it has different uses. Thus, we define clusters for this approach as the set of zones with the same use. In terms of models, this corresponds to all zones within a single model.

2.2 Calculating Cluster Loads

Once these groupings have been identified, calculating their load is fairly straightforward. In the models, we sum the loads of each of the thermal zones that make up the cluster. Since the building’s JSON file has been populated with the name of each zone’s cluster, a single function is sufficient to perform the calculation.

2.3 Calculating Building Loads

Two intermediate steps must be performed before the building loads can be calculated. First, calculate the area of the cluster in the models using the models’ JSON file. Next, calculate the area of each cluster in the desired buildings using the CSV file describing the buildings. Once these steps are completed, the loads for a building are given by \(Q_{building}=\displaystyle\sum_{c \in C_{building}}Q_c \cdot \frac{S_{c,model}}{S_{c,building}}\). Where \(C_b\) is the set of clusters in a building, \(Q_c\) is the load of cluster \(c\), \(S_{c,model}\) is the area of the cluster in the models, and \(S_{c,building}\) is the area of the cluster in the buildings. The area calculations are performed independently for the three building modeling approaches.

3. Generation of the Heating Network

Generating the heating network essentially involves reading and updating certain values in a pre-built heating network file. These template files are based on previous work carried out during a feasibility study for the city of Laval, in which I was tasked with building a heating network model using TRNSYS. These steps use building loads and pipe sizing files from PipingTool as inputs. The model is updated in three areas: equipment operating conditions, pump sizing, and pipe sizing.

3.1 Updating Operating Conditions

Based on peak and annual values for heating and cooling loads, we can redefine the nominal values for the heat pump’s condenser and evaporator, as well as the nominal value for the chiller. We can also update the performance correction factors for the heat pump and the chiller if the system’s operating temperatures change.

3.2.Updating Pumps

For each pump, we can update the maximum flow rate and the maximum loads passing through the pump pipe, thereby defining the pump’s rated power and duty factor at all times.

3.3 Updating Pipes

For each pipe, we update its length, inner and outer diameters, and the thickness of the insulation. By default, we also redefine the thermal conductivity of the insulation and the pipe (which are considered constant in our models).
